ELECTRICALLY HEATED
SERIES 500 STAINLESS STEEL HOSES

MODEL 500 BENDABLE
Model 500 Heat/Line hose features a bendable, smooth bore stainless steel tube for use in fixed applications where tubing is to be bent to the desired configuration and where flexibility is not required. Unique features include a built-in electrical heating element which provides temperatures up to 600 degrees F (315 degrees C). The electrical insulation features a polyimide film with excellent dielectric properties. The hoses come standard with double high temperature thermal insulation, durable scuff resistant jacket and 1" bare tubing on each end.

MODEL 500F FLEXIBLE
This hose features a flexible stainless steel convoluted core for use in applications where limited flexibility is required. It provides non-rigid connections for conveying liquids, gases and semi-solids at temperatures up to 500 degrees F (260 degrees C). It features the same basic construction and materials as our Model 500 Bendable, and is available with JIC female, MNPT, or tube ends.

*Designs available for temperatures up to 1100 degrees F.

MODEL 500EF FLEXIBLE
This hose is the same as our Model 500F, but is more flexible due to its unique construction. It incorporates a built-in electric heating element that provides temperatures up to 450 degrees F (232 degrees C). The electrical insulation is fiberglass reinforced silicone rubber.
